Titanium xov Insert
Titanium Xov Ntxig nrog cov xauv xauv
Heavy Duty Series
Ultra- Lub teeb yuag & Muaj zog
Exceptional tiv thaiv kev co, rub- tawm, hnav, thiab kub heev
TitaniumXov Ntxig nrog xauv cov yuam sij
Qhov tshwj xeeb fastener no nta dual- xov kev tsim kho- sab hauv thiab sab nraud- nrog ob lossis plaub tus yuam sij kaw qhov tseem ceeb nyob rau hauv cov xov sab nraud. Tom qab tau threaded rau hauv ib lub qhov npaj, cov yawm sij yog mus tas li staked rau hauv lub hauv paus cov ntaub ntawv, tsim ib tug heev txhim khu kev qha, vibration-resistant threaded kev twb kev txuas.
Cov yam ntxwv tseem ceeb
• Khoom siv: Qib 5 (Ti-6Al-}4V) Titanium alloy nrog siab zog-rau-qhov hnyav piv thiab zoo heev corrosion kuj.
• Tsim: Cov xov sab hauv thiab sab nraud nrog rau cov yuam sij xauv (feem ntau yog 2 lossis 4 tus yuam sij) rau kev teeb tsa mus tas li.
•Installation: Yooj yim ntsia hlau-hauv thiab nias- haum txheej txheem; cov yuam sij yog staked rau embed rau hauv lub hauv paus khoom.
•Performance: Exceptional tiv thaiv kev co, rub- tawm, hnav, thiab kub heev.
Thawj Qhov Zoo
1.Ultra- Lub teeb yuag & Lub Zog: Zoo tagnrho rau qhov hnyav- cov ntawv siv tau yooj yim (aerospace, motorsports, cov khoom siv kho mob).
2.Corrosion Resistant: Haum rau qhov chaw hnyav (marine, tshuaj lom neeg, kev lag luam sab nrauv).
3.High-Tsub stability: Ua kom muaj kev ncaj ncees nyob rau hauv thermal cycling thiab siab kub.
4.Thread Reinforcement: Upgrades tsis muaj zog los yog puas threads nyob rau hauv cov ntaub ntawv mos (aluminium, magnesium, composites).
Tej kev siv
• Cov khoom siv tub rog thiab tiv thaiv
•Aerospace Cheebtsam
•Railway locomotives
•High -vibration machinery thiab lwm yam kev siv uas yuav tsum tau tshwj xeeb xov lub zog thiab kev ntseeg tau
Yuav ua li cas rau nruab?
1. Qhov Kev Npaj: Laum thiab coj mus rhaub cov khoom siv raws li qhov ntev.
2. Insert Placement: Thread the insert into the tapped qhov kom txog thaum tag nrho zaum.
3. Kev sib koom ua ke tseem ceeb: Siv cov cuab yeej staking los nias lub xauv yuam sij rau hauv cov khoom nyob ib puag ncig.
4. Kev tshuaj xyuas: xyuas kom meej tias tag nrho cov yuam sij yog tag nrho embedded thiab lub insert yog ruaj ntseg xauv.
|
Cov Lus Qhia Tshwj Xeeb rau Hnyav -Lub Luag Haujlwm Thread Insert with Locking Keys |
||||
|
Sab hauv xov |
Sab nraud xov |
Ntev(mm) |
Drill Loj (mm) |
Kais Drill Depth (mm) |
|
M 4x 0.7 |
M 8x1.25 |
8 |
6.9 |
9.5 |
|
M 5x 0.8 |
M10x1.25 |
10 |
8.8 |
12.5 |
|
M 6x 1.0 |
M12x1.25 |
12 |
10.8 |
14.5 |
|
M 8x1.25 |
M14x 1.5 |
14 |
12.8 |
16.5 |
|
M 8x 1.0 |
M14x 1.5 |
14 |
12.8 |
16.5 |
|
M10x 1.5 |
M16x 1.5 |
16 |
14.75 |
18.5 |
|
M10x1.25 |
M16x 1.5 |
16 |
14.75 |
18.5 |
|
M12x1.75 |
M18x 1.5 |
18 |
16.75 |
20.5 |
|
M12x1.25 |
M18x1.5 |
18 |
16.75 |
20.5 |
|
M14x 2.0 |
M20x 1.5 |
20 |
18.75 |
22.5 |
|
M14x 1.5 |
M20x 1.5 |
20 |
18.75 |
22.5 |
|
M16x 2.0 |
M22x 1.5 |
22 |
20.5 |
24.5 |
|
M16x 1.5 |
M22x 1.5 |
22 |
20.5 |
24.5 |
|
M18x 1.5 |
M24x 1.5 |
24 |
22.5 |
26.5 |
|
M20x 2.5 |
M30x 2.0 |
30 |
28 |
34.5 |
|
M20x 1.5 |
M30x 2.0 |
30 |
28 |
34.5 |
|
M22x 1.5 |
M32x 2.0 |
32 |
30 |
36.5 |
|
M24x 3.0 |
M33x 2.0 |
33 |
31 |
37.5 |
|
M24x 2.0 |
M33x 2.0 |
33 |
31 |
37.5 |
